PERFORMANCE
|
|
Processor
|
Intel® Core™ i7-1355U, 10C (2P + 8E) / 12T, P-core 1.7 / 5.0GHz, E-core 1.2 / 3.7GHz, 12MB
|
|
Graphics
|
Integrated Intel® Iris® Xe Graphics functions as UHD Graphics
|
|
Chipset
|
Intel® SoC Platform
|
|
Memory
|
16GB Soldered DDR5-5200
|
|
Memory Slots
|
Models with DDR5 memory: one memory soldered to systemboard, one DDR5 SO-DIMM slot, dual-channel capable
|
|
Max Memory
|
Models with DDR5 memory: up to 32GB (16GB soldered + 16GB SO-DIMM) DDR5-5200
|
|
Storage
|
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
|
|
Storage Support
|
One drive, up to 2TB M.2 2280 SSD
|
|
Storage Slot
|
One M.2 2280 PCIe® 4.0 x4 slot
|
|
Card Reader
|
None
|
|
Optical
|
None
|
|
Audio Chip
|
High Definition (HD) Audio, Realtek® ALC3287 codec
|
|
Speakers
|
Stereo speakers, 2W x2, Dolby® Audio™
|
|
Camera
|
FHD 1080p + IR Hybrid with Privacy Shutter
|
|
Microphone
|
2x, 360°
|
|
Battery
|
Integrated 52.5Wh
|
|
Power Adapter
|
65W USB-C® Slim (3-pin)
|
|
DESIGN
|
|
Display
|
16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, Touch
|
|
Touchscreen
|
On-cell, 10-point Multi-touch
|
|
Keyboard
|
Backlit, English
|
|
Case Color
|
Thunder Black
|
|
Case Material
|
Carbon Fiber Hybrid (Top), PPS (Bottom)
|
|
Dimensions (WxDxH)
|
361.9 x 255.5 x 20.5 mm (14.25 x 10.06 x 0.81 inches)
|
|
Weight
|
Starting at 1.68 kg (3.70 lbs)
|
|
SOFTWARE
|
|
Operating System
|
Windows® 11 Pro, English
|
|
Bundled Software
|
None
|
|
CONNECTIVITY
|
|
Ethernet
|
100/1000M (RJ-45)
|
|
WLAN + Bluetooth
|
Intel® Wi-Fi® 6E AX211, 11ax 2x2 + BT5.3
|
|
WWAN
|
Fibocom L860-GL-16, 4G LTE CAT16, with Embedded eSIM
|
|
SIM Card
|
None
|
|
NFC
|
None
|
|
Standard Ports
|
1x Ethernet (RJ-45)
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
|
|
Docking
|
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® T16 Gen 2 (Intel®)
|
|
Monitor Cable
|
None
|
|
SECURITY & PRIVACY
|
|
Smart Card Reader
|
None
|
|
Security Chip
|
Discrete TPM 2.0 Enabled
|
|
Fingerprint Reader
|
Touch Style, Match-on-Chip, Integrated in Power Button
|
|
Physical Locks
|
Kensington® Nano Security Slot™, 2.5 x 6 mm
|
|
Other Security
|
Camera privacy shutter
IR camera for Windows® Hello
Glance by Mirametrix®
Ultrasonic Human Presence Detection (IR camera models)
|
|
MANAGEABILITY
|
|
System Management
|
Non-vPro®
|
|
ACCESSORIES
|
|
Bundled Accessories
|
None
|
|
CERTIFICATIONS
|
|
Green Certifications
|
ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified 9.0
|
|
Mil-Spec Test
|
MIL-STD-810H military test passed
|
